| Specification |
|
|
Model:
|
GS-LS/HT-New
|
|
Light source life:
|
>100000hours
|
|
Light source:
|
LED
|
|
Power supply:
|
Mono crystalline silicon solar panel
|
|
Battery capacity:
|
12.8V45AH
|
|
Battery type:
|
LiFePO4 battery
|
|
Battery life:
|
>5 years
|
|
Solar panel power:
|
6wx4
|
|
Solar panel voltage:
|
16.5V
|
|
Solar panel life:
|
>20years
|
|
Power consumption:
|
15W
|
|
Vertical divergence:
|
3°
|
|
Horizontal out-put:
|
360°
|
|
Visual range:
|
6-12NM
|
|
Overall size(mm):
|
265*265 *542
|
|
Installation size(mm):
|
210~246* M10*4pcs
|
|
Weight:8
|
Kg
|
|
Emitting color:
|
Red,white,yellow,green,blue
|
|
Storage temperature:
|
-40℃~+70℃
|
|
Working temperature:
|
-10℃~+60℃
|
|
Wind load:
|
80m/s
|
|
Working mode:
|
Flashing 20times/min
|
|
Light Characteristics:
|
IALA standard 350 lights Characteristics adjustable
|
|
Protection Standard:
|
IP68
|
|
Continuous working time:
|
15days(10hours a day)
|
|
Optically Controlled Ambient Brightness:
|
300±100LUX
|
Function & Features
1.Continuous working time in rainy day can reach more than 15 days (10 hours a day).
2.Photocell can switch ON/OFF the light in rainy days or at night automatically.
3.Standardization of optical design, high photoelectric conversion efficiency.
4.Double light source design, it can improve service life for times and safety.
5.Special LED chips with brightness,high conversion efficient and long life.
6.Provide ability of lightning protection, light fastness, resist snow and rain.
7.LED technology, working stable, save cost of maintain.
8.Internal use renewable solar dedicated lead-acid battery, service life can reach more than 2 years.
9.Can customize lithium iron phosphate battery to improve service life and working temperature range.
Usage notice
1.Please read the instruction carefully and then use the device correctly.
2.Solar powered Aviation obstruction light must be installed in a sunny place to keep it working continuously.
3.Please install this light on the Installation plane that perpendicular to light axis, installation plane should has mechanical strength.
4.If the device fails to work at the first using time, please place the device under sunlight to recharge power 12hours, it will work.
5.Please turn off the device and put it in a sunlight for 5day(s) to recharge power each 3 months if it needs to be stored for a long time.
6.If there any other problem please contact us.
Application
Sea buoy, River way, Shore beacon, Fixed light pile, Lighthouse, Oilfield , Derrick
Dimension drawing
