CAAC Approved High-intensity Type B Aircraft Obstacle Light

Item No.: TX-HB-01(L)
1. Casting aviation aluminum shell, fully sealed structure.
2. High brightness SMT LED chip,combine double layers overlay reflective optical structure.
3. Management circuit with Strong lightning protection.
4. Conform to MH/T6012-2015 standard.
Model :  TX-HA-01L)                            Vertical Divergence :
Power supply : AC220VDC180V                                     Horizontal Out-put : 90°
Power frequency : 50HZ60HZ                                         Overall Size : 570*190*266mm (L*W*H) (mounting foot outer mounting)
538*190*266mm (L*W*H) (mounting food inner mounting)
Average power : ≤15W                                                       Installation size : 550*90*M10(mounting foot outer mounting)
                                                                                                                       480*90*M10(mounting food inner mounting)
Working mode : Flash 40~60 times/min                             Ambient Temperature : -40℃~+55
Emitted color : White                                                          Weight : 11.6kg(not include mounting bracket)
Light source : LED                                                             Wind load : 240km/h
Shell material : Aviation Aluminum alloy                            Luminous mirror material : optical glass
Energy efficiency : ≥95%                                                   Light source lifespan : ≥200000h
Protection grade : IP65                                                     Surge protection rating : 5KA
Relative humidity : 0%~95%                       Get wet in the rain : Can be exposed to rain in any wind direction
Salt spray :Can be exposed to salt spray                         Radiation : Can be exposed to solar radiation
Leakage current :10uA                                                  Electric shock protection :Has
Altitude : 2500m
Installing structure : Adaptive vertical installation or side vertical installation
Insulation characteristic : Between the input end and the shell: 1.414kVDC, 10s no breakdown
Seismic resistance : 10500Hz,2G 10min/cycle,XYZ 60 minutes for each axis
EMC standards: Emitted:EN55022(CISPR2 2) class A harmonic wave:EN61000-3-2,-3 Mean Time Between : Failure ≥200000h,MIL-HDBK-217 F(25)
Effective intensity : Daytime 100000cd,dawn/twilight 20000cdnight 2000cd
Photocell stage : Night(50Lx) ,dawn(50-500Lx),daytime(500Lx),twilight(50-500Lx)

  1. Housing adopt high intensity casting aviation aluminum, fully sealed structure.
  2. Adopt high efficient SMT LED chip, which have the specific of high brightness, low power consumption and long long lifespan.
  3. Adopt with independent research and development advanced optical lighting systemSpotlight angle meets CAAC and ICAO requirements.
  4. With surge protection device, which can adopt to extremely bad working environment.
  5. Adopt advanced high high thermal conductive stoving varnish technology, which provide excellent heat dissipation, it can shortage lamp’s weight and volume efficiently
  6. With the impact resistance, anti lightning, resistant to sunlight, anti snow, can resist typhoons, hail and other severe weather.
  7. With over-current protection function.
  8. It can be customized functions of GPS Beidou wireless synchronization, LORA-10KM wireless sync, Remote control and telemetering.

Attention / Usage Tips
  1. Don't use any out of nominal voltage,or will destroy equipment.
  2. Do not open it if the device is out of operation, in order not to be hurt by the internal high pressure.
  3. After finished the installation, the personnel must check whether the device is in a good waterproof processing and whether the screw spikes are tightened.
  4. Non-professional workers can not do the device maintenance, in order not to expand the error and be hurt.

Block, Airport, high-pole lamp, Chimney, Bridge, Towers, Communication tower, super high building.
